Description
| MODEL NO | GEB051200A-B-GBP2 | GEB051280A-B-GBP2 | GEB051320A-B-GBP2 | |
| Battery Chemistry | LiFePO4 | |||
|
Capacity (Ah) |
200 | 280 | 320 | |
| Scalability | Max.16pcs in parallel (162kWh) | Max.16pcs in parallel (229kWh) |
Max.16pcs in parallel (262kWh) | |
|
Nominal Voltage (V) |
51.2 | |||
| Operating Voltage (V) | 46-56 | |||
|
Energy (kWh) |
10.24 | 14.34 | 16.38 | |
|
Usable Energy (kWh) |
9.22 |
12.91 |
13.10 | |
|
Charge/Discharge Current (A) |
Recommend |
100 | ||
|
Max. |
150 | |||
|
Peak(2mins,25℃) |
200 | |||
| Other Parameter | ||||
| Recommend Depth of Discharge | 80% | |||
| Dimension (W/H/D,mm) | 550*800*160 | 900*675*200 | 900*675*200 | |
|
Weight Approximate (kg) |
102.50 | 128.50 | 146.50 |
|
| Master LED Indicator | 4 LED (SOC:25%~100%) | |||
| 2 LED (working, alarming, protecting) | ||||
|
IP Rating of Enclosur |
IP65 | |||
| Working Temperature | Charge:0℃～55℃ Discharge:-20℃～55℃ | |||
|
Storage Temperature |
0℃～35℃ | |||
| Humidity | 5%~95% | |||
| Altitude | ≤2000m | |||
| Cycle Life (25±2℃,0.5C/0.5C,80%EOL) | ≥6500 | ≥8500 | ||
| Installation | Wallmounted | |||
| Communication Port | CAN2.0, RS485 | |||
| Warranty Period | 10 years | |||
| Certification | IEC-62619, CE-EMC, MSDS, UN38.3 |
UL9540A, UL9540, UL1973, IEC-62619, CE-EMC, MSDS, UN38.3 |
IEC-62619, CE-EMC, MSDS, UN38.3 | |
