Description
| Model No | GEB-R20K |
GEB-R30K | GEB-R40K | GEB-R50K | GEB-R60K |
|
Nominal Capacity
|
20.48kWh | 30.72kWh | 40.96kWh | 51.20kWh | 61.44kWh |
|
Cell Matching
|
64S1P
|
96S1P | 128S1P | 160S1P | 192S1P |
|
Working Voltage Range |
176-230.4V
|
268.8-345.6V
|
358.4-460.8V
|
448-576V | 537.6-691.2V |
|
Nominal Voltage
|
204.8V |
307.2V | 409.6V | 512V | 614.4V |
|
Weight
|
396.4 kg | 479.6 kg | 562.8kg | 646kg | 729.2kg |
|
Dimension (WxDxH)
|
553*503*1011mm | 553*503*1620mm | 553*503*1620mm | 553*503*2230mm | 553*503*2230mm |
|
Battery Type
|
LFP(LiFePO4)
|
||||
|
Nominal Working Current
|
100A | ||||
|
Communication Port
|
CAN/RS485
|
||||
|
Working Temperature Rang
|
Charge:0-55°C/Discharge:-20-55°C
|
||||
|
Waterproof
|
IP20
|
||||
|
Installation Method
|
Floor-standing
|
||||
|
Cycle Life
|
10 years
|
||||
|
Peak Charge/Discharge Current (@25°C,5S) |
150A
|
||||
|
Discharge Rate of Module
|
≤3.5%/month/@25°C
|
||||
