Description
| MODEL NO |
GEB051280A-B-GBP2 |
GEB051320A-B-GBP2 |
|
| Battery Chemistry | LiFePO4 | ||
|
Capacity (Ah) |
280 |
320 | |
| Scalability | Max.16pcs in parallel (229kWh) | Max.16pcs in parallel (262kWh) | |
|
Nominal Voltage (V) |
51.2 | ||
| Operating Voltage(V) | 46-56 | ||
|
Energy (kWh) |
14.34 | 16.38 | |
|
Recomend Discharge Energy (80% DOD) (kWh) |
13.10 | 14.70 |
|
|
Charge/Discharge Current (A) |
Recommend |
100 |
100 |
|
Max. |
150 | 150 | |
|
Peak(2mins,25℃) |
200 | 200 | |
| Other Parameter | |||
| Recommend Depth of Discharge | 80% | ||
| Dimension (W/H/D,mm) | 1200*700*200mm | ||
|
Weight Approximate (kg) |
145.50 | 165.50 | |
| Master LED Indicator | 4 LED (SOC:25%~100%) | ||
| 2 LED (working, alarming, protecting) | |||
|
IP Rating of Enclosur |
IP65 | ||
| Working Temperature | Charge:0℃～55℃ Discharge:-20℃～55℃ | ||
|
Storage Temperature |
0℃～35℃ | ||
| Humidity | 5%~95% | ||
| Altitude | ≤2000m | ||
| Cycle Life (25±2℃,0.5C/0.5C,80%EOL) | ≥8500 | ≥10000 | |
| Installation | Outdoor&Ground | ||
| Communication Port | CAN2.0, RS485 | ||
| Warranty Period [3] | 15 years | ||
| Certification |
UL1973, UL9540A, CB-IEC62619, CE-EMC, MSDS, UN38.3 |
||
