Introducing our latest addition to the electric vehicle charging solutions, the New 220V Level 2 EVSE Charger. This 7kW, 32A EV Wallbox is a state-of-the-art charging station designed for home use, offering a convenient and efficient way to power up your electric car.
With its GB/T compatibility, this charger ensures broad compatibility with various electric vehicles, making it a versatile choice for most EV owners. The sleek and modern design complements any home décor, seamlessly integrating into your living space.
The Level 2 charging technology delivers faster charging speeds than standard Level 1 chargers, significantly reducing the time needed to fully charge your vehicle. This, coupled with its user-friendly interface and advanced safety features, ensures a smooth and secure charging experience.
Embark on a journey towards a more sustainable future with our New 220V Level 2 EVSE Charger. Order now and enjoy the convenience of charging your electric car at home, without any hassle.
Products Description:
Details Images:
Category | Specifications | JY512 -11.6K(Type 1) | JY512 -7.6kw(Type 1) | JY512-7KW(GBT) | |
Standard | EMC/Safety | Compliant with IEC 61851-21-2:2018 ; IEC 61851-1:2010/EN 61851-1:2017/IEC 61851-21-2:2018 | |||
protection Class | IP55 | ||||
Equipment information | Mounting | Wall mounted/column mounted | |||
Dimensions(W*D*H mm) | 270mm*180mm*400mm | ||||
Weight(kg) | 7 | ||||
shell Material | Nonmetallic materials | ||||
Working environment | Ambient temperature | -30 ~ +50°C | |||
Storage temperature | -40 ~ +70°C | ||||
Working humidity | 0 ~ 95% | ||||
Working altitude | ≤2000 m without derated | ||||
Input parameters | AC Frequency | 45-65Hz | |||
AC Voltage | 3-phases+N+PE,400±10%Vac | ||||
output parameters | output voltage | 3-phases+N+PE,400±10%Vac | |||
output current | 1-p 48 ac | 1p 24a ac | 1p-32a | 3p-16a | |
Rated power | 11.5kw | 7.6K | 7kw | 11kw | |
Function and Interface | User interface | RFID,panel LED | |||
charging standards | case C | ||||
Metering | 1 AC energy meter | ||||
Monitor interface | OCPP 1.6J , LAN and optional 4G or WIFI support, RFID authorization | ||||
Charging Protection | Overcurrent and overvoltage | Overcurrent protection, Short circuit protection, Overvoltage protection | |||
GM/I | Protect Earth connect monitoring | ||||
RCD | RCD-A 30mA and DC 6mA mian protection for AC protection |
