Introducing our cutting-edge EV Charger Station, a dual-mode device that incorporates WiFi, RFID, and Bluetooth technology for seamless charging experiences. This Level 2 AC charger not only offers exceptional charging speeds but also boasts advanced features for ultimate convenience and safety.
With its dual DUNS capabilities, this charger station is compatible with a wide range of electric vehicles, ensuring compatibility with most makes and models. The built-in WiFi allows for remote monitoring and control, giving you the freedom to manage your charging sessions from anywhere.
The RFID and Bluetooth functionalities add another layer of security and personalization, allowing only authorized users to access the charger. The sleek and modern design complements any garage or parking space, making it a stylish addition to your electric car charging setup.
Experience the ultimate in EV charging technology with our WiFi, RFID, Bluetooth Dual DUNS AC Level 2 EV Charger Station. Order now and enjoy the convenience, safety, and reliability that this charger station offers.
Products Description:
Details Images:
Category | Specifications | JY511-22K | JY511-11K | JY511-7K-A | JY511-7K-B |
| EMC/Safety | Compliant with IEC 61851-21-2:2018 ; IEC 61851-1:2010/EN 61851-1:2017/IEC 61851-21-2:2018 | |||
protection Class | IP55/IP 66 | ||||
Equipment information | Mounting | Wall mounted/column mounted | |||
Dimensions(W*D*H mm) | 270mm*180mm*400mm | ||||
Weight(kg) | 10kg | ||||
shell Material | Nonmetallic materials | ||||
| Ambient temperature | -30 ~ +50°C | |||
Storage temperature | -40 ~ +70°C | ||||
Working humidity | 0 ~ 95% | ||||
Working altitude | ≤2000 m without derated | ||||
| AC Frequency | 45-65Hz | |||
AC Voltage | 3-phases+N+PE,400±10%Vac | ||||
| output voltage | 3-phases+N+PE,400±10%Vac | |||
output current | 32A ac | 3-phases 16A ac | 1-phase 32A ac | ||
Rated power | 22kw | 11kw | 7KW | ||
Function and Interface | User interface | RFID,panel LED | |||
charging standards | IEC 62196 Type-2, case C | ||||
Metering | 1 AC energy meter | ||||
Monitor interface | OCPP 1.6J , LAN and optional 4G or WIFI support, RFID authorization | ||||
| Overcurrent and overvoltage | Overcurrent protection, Short circuit protection, Overvoltage protection | |||
GM/I | Protect Earth connect monitoring | ||||
RCD | RCD-A 30mA and DC 6mA mian protection for AC protection |
