Description
Feature
1) Strong common ability:IEC standard frame,it can simply interchange with frequency
conversion three phase asynchronous motor,without any extra cost.
2) High efficiency:low loss silicon steel sheet,high grade rare earth permanent
magnet.Optimization of simulation design verfication,the efficiency grade reaches level 1
energy efficiency.
3) High performance:steady torque,wide constant power range,strong magnetic weakening
ability,wide speed range,rated condition,the temperature rise in electric motors is â¦80k.
4) Adaptive capacity:This series motors can be used with a variety of frequency,low
temperature rise,high effiency.
5) High strength:the motor structure is made of cast iron,it can protect against strong
external shocks.Ensure reliable operation of motor in harsh environment.
6) Control mode:No PG or PG vector control.
7) Vibration level:The maneuvering balance precision of the motor is high.The vibration is
level R.
8) Application:Widely used on compression machine,plastic injection machine,textile
machine,printing machine,blower,water pump and so on.
Technical characteristic
Output power:0.18kw-200kw
Rated voltage:380V,220V
Protection class:IP54,IP55
Cool type:IC416
Working system:S1-100%
Mounting type:B3,B5,B35,B14,B34
Installation dimension:IEC standard.
Condition:Altitude:â¦1000m,environment terperature:-15°C ~ +40°C,relative humidity:â¦80%
Product Description
Specification
item | value |
Warranty | 3months-1year |
Place of Origin | China |
Zhejiang | |
Brand Name | TOPPER |
Model Number | TYCP90S-2.2-30 |
Type | Synchronous Motor |
Frequency | 150Hz |
Phase | Three-phase |
Protect Feature | Totally Enclosed |
AC Voltage | 220/380V |
Efficiency | IE 4 |
Color | Customer Request |
Speed | 2900RPM 1400RPM 960RPM 660RPM |
Cooling method | IC 411 |
Housing | Iron Cast |
Rated Voltage | 220/380V 230/440V 380/660V 400/690V |
Efficiency | IE4 |
Poles | 2/4/6/8/10 |
Wire | 100% Copper Wire |
Mounting | B3 B5 B14 B34 B35 |
Duty | S1 (continuous) |
Packing & Delivery
plywood case,carton box
Company Profile
Taizhou Dongye Electric Motor Co., Ltd. Is located in Daxi Town, which enjoys the convenient transportation of land, air, and sea of the nearby. It is an ideal place for producing and marketing.
We have the markets over 15 countries and regions, such as Philippines, Korea, Viet Nam, Sri Lanka, Bangladesh, Iran, Peru, Ukraine, Russia, Italy, Spain, Poland, etc.
Currently, DONGYE welding machine has formed more than 40 models, which including inverter welding machine, AC arc welding machine, AC/DC functional welding machine, Air plasma cutting machine, battery chargers, etc.
Our company's main products also consist of YC, YL, YCL, YY, JY, MC, MY single phase induction motors and Y, Y2, YS, MS, YCT, YB2,YEJ2 series three phase induction motors, hub motors for e-bicycle and grinding machine for food processing.
For all products information, please logon our website: www.dongyemotor.com for your reference.
We have already got "CE" "CCC" & "ISO 9001" quality certificates.
We have been possessed with rich technical ability and guarantee products quality from precision of production and quality management system. We always consider "Best quality, Highest Reputation, Important clients" as our belief.
Sincerely welcome to visit our company, we would like to cooperate with all the customers over the world to create the splendid future.
FAQ
1. who are we?
We are based in Zhejiang, China, start from 2001,sell to South Asia(30.00%),South America(20.00%),Southeast Asia(20.00%),Western Europe(20.00%),Africa(5.00%),Eastern Asia(5.00%). There are total about 51-100 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Electric Motor,Worm Reducer,AC Gear Motor
4. why should you buy from us not from other suppliers?
The company manufacture the motor and worm reducer together.It is convenient to the customer. The company have more than 10 years' experience to produce electirc motor,we have strictly quality control system.
5. what services can we provide?
Accepted Delivery Terms: FOB,CIF,EXW,Express Deliveryï¼
Accepted Payment Currency:USD,CNY;
Accepted Payment Type: T/T,L/C;
Language Spoken:English,Chinese
We are based in Zhejiang, China, start from 2001,sell to South Asia(30.00%),South America(20.00%),Southeast Asia(20.00%),Western Europe(20.00%),Africa(5.00%),Eastern Asia(5.00%). There are total about 51-100 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Electric Motor,Worm Reducer,AC Gear Motor
4. why should you buy from us not from other suppliers?
The company manufacture the motor and worm reducer together.It is convenient to the customer. The company have more than 10 years' experience to produce electirc motor,we have strictly quality control system.
5. what services can we provide?
Accepted Delivery Terms: FOB,CIF,EXW,Express Deliveryï¼
Accepted Payment Currency:USD,CNY;
Accepted Payment Type: T/T,L/C;
Language Spoken:English,Chinese
