Description
Specification
item | value |
Warranty | 1year |
Place of Origin | ZHE |
Brand Name | TOPPER |
Model Number | TYCP-90S-2.2KW |
Type | Synchronous Motor |
Frequency | 150Hz |
Phase | Three-phase |
Protect Feature | Totally Enclosed |
AC Voltage | 220V,380V |
Efficiency | IE4 |
Application | compression machine,plastic injection machine |
Color | Blue,Black,Silver,customize |
Speed | 3000rpm |
Voltage | 220/380 |
Rated Power | 2.2KW |
Protection class | IP55 |
Efficiency | IE4 |
Brand | TOPPER |
Poles | 2POLES |
Material | Copper wire |
Packing & Delivery
plywood case,carton box
Company Profile
Future:
* Strong common ability:IEC standard frame,it can simply interchange with frequency conversion three phase asynchronousmotor,without any extra cost.
* High efficiency:low loss silicon steel sheet,high grade rare earth permanent magnet.Optimization of simulation design
verfication,the efficiency grade reaches level 1 energy efficiency.
* High performance:steady torque,wide constant power range,strong magnetic weakening ability,wide speed range,rated condition,the temperature rise in electric motors is ≦ 80K
* Adaptive capacity:This series motors can be used with a variety of frequency,low temperature rise,high effiency.
* High strength:the motor structure is made of cast iron,it can protect against strong external shocks.Ensure reliable operation of motor in harsh environment.
* Control mode:No PG or PG vector control.
* Vibration level:The maneuvering balance precision of the motor is high.The vibration is level R.
* Application:Widely used on compression machine,plastic injection machine,textile machine,printing machine,blower,water pump and so on.
Technical characteristic
Output power:0.18kw-200kw
Rated voltage:380V,220V
Protection class:IP54,IP55
Cool type:IC416
Working system:S1-100%
Mounting type:B3,B5,B35,B14,B34
Installation dimension:IEC standard.
Condition:Altitude:≦1000m,environment terperature:-15°C ~ +40°C,relative humidity:≦80%
