Description
Product Description
Model No.: NMRV/NRV025, 030, 040, 050, 063, 075, 090, 110, 130
Reduction gear, worm gear, gear reducer
Reduction gear
Features:
1) High quality aluminum alloy die cast gearbox
2) High accuracy worm gear and worm shaft
3) Less noise and lower temperature increase
4) Easy mounting and linking, high efficiency
5) Power: 0.06 - 15kW
6) Output torque: 2.7 - 1, 760Nm
7) Transmission rate: 5 - 100
Inner packing: Carton Outer packing: Wooden case
Reduction gear, worm gear, gear reducer
| Motor performance Parameters | |||||||||||
| Model | Rated power | Voltage | FrequencyPoles | Rated Speed | Starting torque | Rated torque | Rated Current | Capacitor | Rated Time | ||
| RAY SHAFT | GEAR SHAFT | ||||||||||
| 5IK40A-A | 5IK40GN-A | 40 | 1Phase /110 | 50/60 | 4 | 1300/1600 | 2.7 | 3 | 0.65 | 10/250 | CONT |
| 5IK40A-C | 5IK40GN-C | 40 | 1Phase /220 | 50/60 | 4 | 1300/1600 | 2.7 | 3 | 0.33 | 2.5/450 | CONT |
| 5IK40A-Y | 5IK40GN-Y | 40 | 3Phase 220/380 | 50/60 | 4 | 1300/1600 | 9.7 | 3 | 0.31/0.18 | - | CONT |
| 5RK40A-A | 5RK40GN-A | 40 | 1Phase 110 | 50/60 | 4 | 1300/1600 | 2.5 | 2.8 | 0.65 | 12/250 | 30Minutes |
| 5RK40A-C | 5RK40GN-C | 40 | 1Phase /220 | 50/60 | 4 | 1300/1600 | 2.5 | 2.8 | 0.33 | 3/450 | 30Minutes |
| 5RK40A-Y | 5RK40GN-Y | 40 | 3Phase 220/380 | 50/60 | 4 | 90-1300/90-1600 | 9.5 | 2.8 | 0.31/0.18 | - | 30Minutes |
| 5IK40RA-A | 5IK40RGN-A | 40 | 1Phase /110 | 50/60 | 4 | 90-1300/90-1600 | 1.7 | 3 | 0.65 | 10/250 | CONT |
| 5IK40RA-C | 5IK40RGN-C | 40 | 1Phase /220 | 50/60 | 4 | 1.7 | 3 | 0.33 | 2.5/450 | CONT | |
Detailed Images
Certifications
Packaging & Shipping
Company Information
FAQ
1. Q: Are you a factory or trading company? A: Julante is a factory that has been focusing on motors and accessories for more than
25 years.
2. Q: Can you do OEM ?
A: Yes. We offer OEM/ODM service.but if you use our brand,you will get the amazing price.
3. Q: Can you accept the customized products?
A:Yes, of course.We accept your specific order if you can provide us your
specialrequirements or your special samples.
4. Q: How about your service?
A: We have pre-sale service,in-sale service and after-sale service.What we pursue is long-term cooperation,so our principle is
customer first.
5. Q:What’s the delivery time ?
A: 20 to 30 days after receiving your payment in advance.
