Description
TH-739A FEATURES:
●The rising stop point and the drafting stop point of the newly designed last supporter are adjusted speedily and externally,accompanied by the digitized position indicator, with a precision up to 0.1mm, which is the most accurate repeatability.
●There are two speed-changing modes to choose when the last supporter is rising, it can improve the efficiency of production,especially for the fragile vamps.
●The machine can be installed additionally with the auxiliary wiper and automatic cementing mechanism body depending needs.
●Use the encoder to control the lasting mode, which can greatly shorten the adjustment time compared with the traditional manual adjustment.
●This machine features shoe memory and storing 100 shoe models.
Model: TH-739A Pincers: 9
Voltage: 380V Heating Power: 1.75kw
Oil Pressure:50kg/cm² Productivity:2000pairs/8hour
Oil Filling: 115liters N.W.:1220kg
Dimension: 1750(L)*980(W)*1950(H) mm
Packing Size: 1860(L)*1030(W)*2160(H)mm
