Products Description
project name | KS928 | ||
Sawing length | 2800mm | Sawing width | 2800mm |
sawing thickness | 100mm | Targeting | automatic |
positioning accuracy | ±0.02mm | Sawing accuracy | ±0.15mm |
Main saw motor power | 15kw | Main saw blade outer diameter | 400mm |
Main saw shaft diameter | 75mm | Main saw speed | 4100 r/min |
Saw traction motor power | 2.0kw | Robot servo motor | 2.0kw |
Auxiliary saw motor power | 1.5kw | Auxiliary saw blade outer diameter | 200mm |
Auxiliary saw shaft diameter | 45mm | Auxiliary saw speed | 6200 r/min |
Feeding speed | 0-100M/min | Sawing speed | 0-100M/min |
return speed | 0-120M/min | air pressure | 0.6-0.8 MPA |
Centrifugal fan | 3kw | total power | 23.5kW |
Working surface thickness | Main 25mm, sub 16mm | Gear and rack error within 1M | 0.02mm |
Pressing method | Cylinder clamp press | color standard | Blue and white |
Dimensions | 5150*6100*2000mm |
